YBH140-10 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 10 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 250mm,

　　Equipped motor: 5.5KW,

　　Dimensions: 1.6 * 1.2 * 1.6 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 89/φ 76,

　　Weight: 0.85 tons,

　　Fuel tank capacity: 170L

　　Huaxing Pump YB200-19-800 Size

　　YBH200-19 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 19 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 250mm,

　　Equipped motor: 7.5KW,

　　Dimensions: 1.7 * 1.3 * 1.9 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 108/φ 89,

　　Weight: 1.1 tons,

　　Fuel tank capacity: 210L

　　Huaxing Pump YBH250-30-800 Size

　　YBH250-30 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 30 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 250mm,

　　Equipped with motor: 11KW,

　　Dimensions: 1.95 * 16 * 2.2 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 133/φ 108,

　　Weight: 1.63 tons,

　　Fuel tank capacity: 310L

　　YB300-40 Hydraulic Ceramic Piston Mud Pump-800 Size

　　YBH300-40 filter press energy-saving ceramic plunger mud pump

　　Flow rate: 40 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 250mm,

　　Equipped motor: 15KW,

　　Dimensions: 2.1 * 1.8 * 2.2 meters),

　　Diameter of suction and discharge slurry pipeline: φ 140/φ 140,

　　Weight: 2.1 tons,

　　Fuel tank capacity: 310L

　　Huaxing Pump YBH300-60-800 Size

　　YBH300J-60 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 60 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 350mm,

　　Equipped motor: 18.5KW,

　　Dimensions: 2.1 * 1.8 * 2.5 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 159/φ 159,

　　Weight: 2.6 tons,

　　Fuel tank capacity: 390L

　　Huaxing Pump YBH300-80-800 Size

　　YBH300J-80 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 80 cubic meters per hour,

　　Pressure range: 0-2MPa,

　　Rated pressure: 0-20 kg can be adjusted freely,

　　Stroke: 350mm,

　　Equipped motor: 22KW,

　　Dimensions: 2.1 * 2 * 2.5 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 159/φ 159,

　　Weight: 2.6 tons,

　　Fuel tank capacity: 390L

　　YBH400-100 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 100 cubic meters per hour,

　　Pressure range: 0-1.8MPa,

　　Rated pressure: 0-15 kilograms can be adjusted freely,

　　Stroke: 350mm,

　　Equipped motor: 22KW,

　　Dimensions: 2.48 * 2.5 * 2.6 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 180/φ 159,

　　Weight: 3.8 tons,

　　Fuel tank capacity: 560L

　　YBH400-120 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 120 cubic meters per hour,

　　Pressure range: 0-1.5MPa,

　　Rated pressure: 0-15 kilograms can be adjusted freely,

　　Stroke: 350mm,

　　Equipped with motor: 30KW,

　　Dimensions: 2.48 * 2.5 * 2.6 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 180/φ 159,

　　Weight: 3.8 tons,

　　Fuel tank capacity: 560L

　　YBH400-180 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 180 cubic meters per hour,

　　Pressure range: 0-1.5MPa,

　　Rated pressure: 0-15 kilograms can be adjusted freely,

　　Stroke: 350mm,

　　Equipped motor: 45KW,

　　Dimensions: 2.48 * 2.5 * 2.6 (meters),

　　Diameter of suction and discharge slurry pipeline: φ 180/φ 159,

　　Weight: 3.8 tons,

　　Fuel tank capacity: 560L

　　YBH500-180

　　YBH500-180 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 180 cubic meters per hour,

　　Pressure range: 0-1.5MPa,

　　Rated pressure: 0-15 kilograms can be adjusted freely,

　　Stroke: 450mm,

　　Equipped motor: 45KW,

　　Dimensions: 3.8 * 2.2 * 3 (meters),

　　Diameter of suction and discharge slurry pipeline: DN200/DN200

　　YBH400-240

　　YBH500-240 filter press energy-saving ceramic plunger pump mud pump

　　Flow rate: 240 cubic meters per hour,

　　Pressure range: 0-1.5MPa,

　　Rated pressure: 0-15 kilograms can be adjusted freely,

　　Stroke: 450mm,

　　Equipped motor: 67KW,

　　Dimensions: 3.8 * 2.2 * 3 (meters),

　　Diameter of suction and discharge slurry pipeline: DN200/DN200
